high precision, high transmission efficiency and long life
Model：MP1935-01
With a design combining high power density and carbon brush commutation, the MP1935-01 brush dc mini motor can deliver a max continuous torque up to 32 mNm. These high torque motors are tailored for the most demanding applications.
Rated Voltage:
12V
Stall Torque:
32±7% mNm
Stall Current:
2±10%A
Constant torque:
16.70±20% mNm/A
Speed Constant:
480±20% rpm/V
Max. efficiency (%):
56
| Motor Data | ||
|---|---|---|
| Nominal voltage(V) | 12 | / |
| No load speed(rpm) | 5850 | +10% |
| No load current (mA) | 0.3 | Max |
| Nominal speed (rpm) | 3870 | ±10% |
| Nominal torque (max. continuous torque) (mNm) | 11 | / |
| Nominal current (max. continuous current) (A) | 0.69 | ±10% |
| Stall torque(mNm) | 32 | ±7% |
| Stall current(A) | 2 | ±10% |
| Max. efficiency (%) | 56 | / |
| Characteristics | ||
|---|---|---|
| Terminal resistance phase to phase (Ω) | 6 | ±10% |
| Terminal inductance phase to phase (mH) | NA | ±10% |
| Torque constant (mNm/A) | 16.7 | ±20% |
| Speed constant (rpm/V) | 480 | ±20% |
| Speed/torque gradient (rpm/mNm) | 190 | ±20% |
| Mechanical time constant (ms) | NA | ±20% |
| Rotor inertia (gcm2) | 4 | ±20% |
You can provide your product requirements to our sales team, and we will select or design the most suitable combination solution for you.
