high precision, high transmission efficiency and long life
Model：MP2238-01
The MP2238-01brush DC motors feature a graphite commutation inside. These miniature motors can deliver a torque up to 90 mNm and an excellent price-to-performance ratio.
Rated Voltage:
12V
Stall Torque:
90±7% mNm
Stall Current:
9±10% A
Constant torque:
18±20% mNm/A
Speed Constant:
540±20% rpm/V
Max. efficiency (%):
65
| Motor Data | ||
|---|---|---|
| Nominal voltage(V) | 12 | / |
| No load speed(rpm) | 6600 | +10% |
| No load current (mA) | 0.4 | Max |
| Nominal speed (rpm) | 5400 | ±10% |
| Nominal torque (max. continuous torque) (mNm) | 20 | / |
| Nominal current (max. continuous current) (A) | 1.5 | ±10% |
| Stall torque(mNm) | 90 | ±7% |
| Stall current(A) | 9 | ±10% |
| Max. efficiency (%) | 65 | / |
| Characteristics | ||
|---|---|---|
| Terminal resistance phase to phase (Ω) | 1.34 | ±10% |
| Terminal inductance phase to phase (mH) | NA | ±10% |
| Torque constant (mNm/A) | 18 | ±20% |
| Speed constant (rpm/V) | 540 | ±20% |
| Speed/torque gradient (rpm/mNm) | 72 | ±20% |
| Mechanical time constant (ms) | NA | ±20% |
| Rotor inertia (gcm2) | 10 | ±20% |
You can provide your product requirements to our sales team, and we will select or design the most suitable combination solution for you.
