high precision, high transmission efficiency and long life
Model：MP2430-03
With a design combining high power density and precious metal commutation, the MP2430-03 mini DC motor can deliver a torque greater than 100 mNm continuously in a very compact package.
Rated Voltage:
12V
Stall Torque:
100±7% mNm
Stall Current:
5.8±10% A
Constant torque:
18±20% mNm/A
Speed Constant:
450±20% rpm/V
Max. efficiency (%):
65
| Motor Data | ||
|---|---|---|
| Nominal voltage(V) | 12 | / |
| No load speed(rpm) | 5600 | +10% |
| No load current (mA) | 0.4 | Max |
| Nominal speed (rpm) | 4400 | ±10% |
| Nominal torque (max. continuous torque) (mNm) | 24 | / |
| Nominal current (max. continuous current) (A) | 1.5 | ±10% |
| Stall torque(mNm) | 100 | ±7% |
| Stall current(A) | 5.8 | ±10% |
| Max. efficiency (%) | 65 | / |
| Characteristics | ||
|---|---|---|
| Terminal resistance phase to phase (Ω) | 2 | ±10% |
| Terminal inductance phase to phase (mH) | NA | ±10% |
| Torque constant (mNm/A) | 18 | ±20% |
| Speed constant (rpm/V) | 450 | ±20% |
| Speed/torque gradient (rpm/mNm) | 52 | ±20% |
| Mechanical time constant (ms) | NA | ±20% |
| Rotor inertia (gcm2) | 10 | ±20% |
You can provide your product requirements to our sales team, and we will select or design the most suitable combination solution for you.
