For higher positioning and speed control, ZHAOWEI provides a wide range of encoders to combine with the complete portfolio of DC motors. offers 2- and 3-channel incremental magnetic and optical encoders with standard quadrature resolution from 16 to up to 10,000 pulses per revolution or single-turn absolute encoders with a resolution of up to 4 ,096 steps.
Optical encoders are characterised by a very high position and repeat accuracy as well as a very high signal quality due to the precise measuring element. Furthermore, they are insensitive to magnetic interference. In optical encoders, a code disc with a measuring element is used that is attached to the shaft of the DC motor. A distinction is made here between reflective and transmissive optical encoders.
※: The Encoder is not sold separately, and needs to be sold as a whole with the motor+gearbox
The pulse number of each week of rotation：1~1024
Encoder channel：2～3
Output signal：Differential ABZ/UV/ UVW Single end ABZ
Work current, typical value (mA) ：10
Power supply voltage（V）：3.3~5
Maximum speed (rpm)：55000
Incremental encoders with high accuracy with modular design
The incremental encoders from ZHAOWEI are constructed according to optical or magnetic principles as well as in a single-chip version. The encoder supplies two 90° phase-shifted square wave signals with up to 10,000 pulses. In the 3-channel version, an additional index pulse is available per motor revolution.
