Shenzhen ZHAOWEI Machinery & Electronics Co., Ltd

16mm Metal Planetary Gearbox

Model: ZWMD016016

Diameter
16mm
Voltage Range
3-24V
Reduction Ratio
4-1296
Max. Transmittable Power
2W
Max. Continuous Torque
0.5Nm
Rated Speed Range
6-1875rpm
Operating Temperature
-30…+100℃


Application:Industrial automation, special equipment, smart medical products, etc

Gearbox Specifications:

Bearing Porous bearing Rolling bearing
Axial Endplay ≤0.3mm ≤0.3mm
Radial Loading on Output Shaft ≤20N ≤30N
Operating Temperature -30℃ ~ +100℃

Parameters:

Gearbox Stages 1 2 3 4
Reduction Ratio 4/6 16/24/36 64/96/144/216 256/384/576/864/1296
Max Rated Torque (gf.cm max) 5,000 5,000 5,000 5,000
Max Instant Torque (gf.cm max) 10,000 10,000 10,000 10,000
Gearbox Efficiency (%) 90 85 80 70
Length (mm) 11.5 14.8 18.1 21.4
Gear backlash ≤3° Customizable

Drawing:

MD16mm technical drawing

Motor Specifications:

Motors (Optional) Brushed DC Motor,BrushlessDC Motor,Coreless Motor, Stepper Motor
Voltage (Optional) 3-24V
Input Speed ≤15,000rpm
Current 300mA max

Performance Data:

Model Rated Speed
(rpm)
 Max Speed
(rpm)
Max Rated Torque (gf.cm) Max Instant Torque
(gf.cm)
Gear Ratio  Length
 (L1)
(mm)
Overall Length
(L)
(mm)
ZWMD016016-4 1875 7500 5000 10000 4 11.5 38.4
ZWMD016016-6 1250 5000 5000 10000 6
ZWMD016016-16 469 1875 5000 10000 16 14.8 41.7
ZWMD016016-24 313 1250 5000 10000 24
ZWMD016016-36 208 833 5000 10000 36
ZWMD016016-64 117 469 5000 10000 64 18.1 45
ZWMD016016-96 78 313 5000 10000 96
ZWMD016016-114 52 208 5000 10000 144
ZWMD016016-216 35 139 5000 10000 216
ZWMD016016-256 29 117 5000 10000 256 21.4 48.3
ZWMD016016-384 20 78 5000 10000 384
ZWMD016016-576 13 52 5000 10000 576
ZWMD016016-864 9 35 5000 10000 864
ZWMD016016-1296 6 23 5000 10000 1296

* The above specifications are subject to change without prior notice. They are for reference only and can be customized as required.
